Tech parameter
|
Description
|
|
Up-link interface |
1 GPON interface, SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s rate
Fiber type：SC/UPC TX Optical power：0~4dBm RX Sensitivity：-28dBm Safety: ONU authentication mechanism |
|
Wavelength(nm)
|
TX 1310nm，RX 1490nm
|
|
Fiber connector
|
SC/UPC connector
|
|
Down-link data interface
|
1*10/100Mbps and 1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface
|
|
Indicator LED
|
8 pcs，refer to NO.6 definition of indicator LED
|
|
DC supply interface
|
input＋12V 1A，footprint：DC0005 ø2.1MM
|
|
Power
|
≤5W
|
|
Operating temperature
|
-5～+55℃
|
|
Humidity
|
10～85%（non-condensation）
|
|
Storage temperature
|
-30～+70℃
|
|
Dimension（MM）
|
185*125*32mm（mainframe）
|
|
Weight
|
0.3Kg（mainframe）
|
|
WIFI Characteristics
|
|
|
Tech features
|
Description
|
|
Antenna
|
2T2R Mode gain:5dBi
|
|
Rate
|
IEEE802.11b/g/n: 300Mbps Channel number:13 for wifi4
|
|
Encryption methods
|
WFAã€WPAã€WPA2ã€WAPI
|
|
Tx power
|
17dBm for 2.4GHz
|
|
Rx sensitivity
|
WIFI4：-59dBm @ channel 11 MCS7
|
|
WPS function
|
Support
|
|
Ordering Information
|
|
|
Model No.
|
Descriptions
|
|
PG-2202XR
|
1GE+1FE+Wifi EPON GPON XPON ONU/ONT
|
